Background
In Windows 10 (version RS4), Microsoft introduced the Windows Hypervisor Platform (WHP) API. This API exposes Microsoft's built-in hypervisor functionality to user-mode Windows applications. In 2024, the author used this API to create a personal project: a 16-bit MS-DOS emulator called DOSVisor. As mentioned in the release notes, there have always been plans to take this concept further and use it to emulate Windows applications. Elastic provides a research week (ON Week) twice per year for staff to work on personal projects, providing a great opportunity to begin working on this project. This project will be (unimaginatively) named WinVisor, inspired by its DOSVisor predecessor.
Hypervisors provide hardware-level virtualization, eliminating the need to emulate the CPU via software. This ensures that instructions are executed exactly as they would be on a physical CPU, whereas software-based emulators often behave inconsistently in edge cases.
This project aims to build a virtual environment for executing Windows x64 binaries, allowing syscalls to be logged (or hooked) and enabling memory introspection. The goal of this project is not to build a comprehensive and secure sandbox - by default, all syscalls will simply be logged and forwarded directly to the host. In its initial form, it will be trivial for code running within the virtualized guest to "escape" to the host. Safely securing a sandbox is a difficult task, and is beyond the scope of this project. The limitations will be described in further detail at the end of the article.
Despite having been available for 6 years (at the time of writing), it seems that the WHP API hasn’t been used in many public projects other than complex codebases such as QEMU and VirtualBox. One other notable project is Alex Ionescu's Simpleator - a lightweight Windows user-mode emulator that also utilizes the WHP API. This project has many of the same goals as WinVisor, although the approach for implementation is quite different. The WinVisor project aims to automate as much as possible and support simple executables (e.g. ping.exe) universally out of the box.
This article will cover the general design of the project, some of the issues that were encountered, and how they were worked through. Some features will be limited due to development time constraints, but the final product will at least be a usable proof-of-concept. Links to the source code and binaries hosted on GitHub will be provided at the end of the article.
Hypervisor basics
Hypervisors are powered by VT-x (Intel) and AMD-V (AMD) extensions. These hardware-assisted frameworks enable virtualization by allowing one or more virtual machines to run on a single physical CPU. These extensions use different instruction sets and, therefore, are not inherently compatible with each other; separate code must be written for each.
Internally, Hyper-V uses hvix64.exe for Intel support and hvax64.exe for AMD support. Microsoft's WHP API abstracts these hardware differences, allowing applications to create and manage virtual partitions regardless of the underlying CPU type. For simplicity, the following explanation will focus solely on VT-x.
VT-x adds an additional set of instructions known as VMX (Virtual Machine Extensions), containing instructions such as VMLAUNCH, which begins the execution of a VM for the first time, and VMRESUME, which re-enters the VM after a VM exit. A VM exit occurs when certain conditions are triggered by the guest, such as specific instructions, I/O port access, page faults, and other exceptions.
Central to VMX is the Virtual Machine Control Structure (VMCS), a per-VM data structure that stores the state of the guest and host contexts as well as information about the execution environment. The VMCS contains fields that define processor state, control configurations, and optional conditions that trigger transitions from the guest back to the host. VMCS fields can be read or written to using the VMREAD and VMWRITE instructions.
During a VM exit, the processor saves the guest state in the VMCS and transitions back to the host state for hypervisor intervention.
WinVisor overview
This project takes advantage of the high-level nature of the WHP API. The API exposes hypervisor functionality to user-mode and allows applications to map virtual memory from the host process directly into the guest's physical memory.
The virtual CPU operates almost exclusively in CPL3 (user-mode), except for a small bootloader that runs at CPL0 (kernel-mode) to initialize the CPU state before execution. This will be described in further detail in the Virtual CPU section.
Building up the memory space for an emulated guest environment involves mapping the target executable and all DLL dependencies, followed by populating other internal data structures such as the Process Environment Block (PEB), Thread Environment Block (TEB), KUSER_SHARED_DATA, etc.
Mapping the EXE and DLL dependencies is straightforward, but accurately maintaining internal structures, such as the PEB, is a more complex task. These structures are large, mostly undocumented, and their contents can vary between Windows versions. It would be relatively simple to populate a minimalist set of fields to execute a simple "Hello World" application, but an improved approach should be taken to provide good compatibility.
Instead of manually building up a virtual environment, WinVisor launches a suspended instance of the target process and clones the entire address space into the guest. The Import Address Table (IAT) and Thread Local Storage (TLS) data directories are temporarily removed from the PE headers in memory to stop DLL dependencies from loading and to prevent TLS callbacks from executing before reaching the entry point. The process is then resumed, allowing the usual process initialization to continue (LdrpInitializeProcess) until it reaches the entry point of the target executable, at which point the hypervisor launches and takes control. This essentially means that Windows has done all of the hard work for us, and we now have a pre-populated user-mode address space for the target executable that is ready for execution.
A new thread is then created in a suspended state, with the start address pointing to the address of a custom loader function. This function populates the IAT, executes TLS callbacks, and finally executes the original entry point of the target application. This essentially simulates what the main thread would do if the process were being executed natively. The context of this thread is then "cloned" into the virtual CPU, and execution begins under the control of the hypervisor.
Memory is paged into the guest as necessary, and syscalls are intercepted, logged, and forwarded to the host OS until the virtualized target process exits.
As the WHP API only allows memory from the current process to be mapped into the guest, the main hypervisor logic is encapsulated within a DLL that gets injected into the target process.
Virtual CPU
The WHP API provides a "friendly" wrapper around the VMX functionality described earlier, meaning that the usual steps, such as manually populating the VMCS before executing VMLAUNCH, are no longer necessary. It also exposes the functionality to user-mode, meaning a custom driver is not required. However, the virtual CPU must still be initialized appropriately via WHP prior to executing the target code. The important aspects will be described below.
Control registers
Only the CR0, CR3, and CR4 control registers are relevant for this project. CR0 and CR4 are used to enable CPU configuration options such as protected mode, paging, and PAE. CR3 contains the physical address of the PML4 paging table, which will be described in further detail in the Memory Paging section.
Model-specific registers
Model-Specific Registers (MSRs) must also be initialized to ensure the correct operation of the virtual CPU. MSR_EFER contains flags for extended features, such as enabling long mode (64-bit) and SYSCALL instructions. MSR_LSTAR contains the address of the syscall handler, and MSR_STAR contains the segment selectors for transitioning to CPL0 (and back to CPL3) during syscalls. MSR_KERNEL_GS_BASE contains the shadow base address of the GS selector.
Global descriptor table
The Global Descriptor Table (GDT) defines the segment descriptors, which essentially describe memory regions and their properties for use in protected mode.
In long mode, the GDT has limited use and is mostly a relic of the past - x64 always operates in a flat memory mode, meaning all selectors are based at 0. The only exceptions to this are the FS and GS registers, which are used for thread-specific purposes. Even in those cases, their base addresses are not defined by the GDT. Instead, MSRs (such as MSR_KERNEL_GS_BASE described above) are used to store the base address.
Despite this obsolescence, the GDT is still an important part of the x64 model. For example, the current privilege level is defined by the CS (Code Segment) selector.
Task state segment
In long mode, the Task State Segment (TSS) is simply used to load the stack pointer when transitioning from a lower privilege level to a higher one. As this emulator operates almost exclusively in CPL3, except for the initial bootloader and interrupt handlers, only a single page is allocated for the CPL0 stack. The TSS is stored as a special system entry within the GDT and occupies two slots.
Interrupt descriptor table
The Interrupt Descriptor Table (IDT) contains information about each type of interrupt, such as the handler addresses. This will be described in further detail in the Interrupt Handling section.
Bootloader
Most of the CPU fields mentioned above can be initialized using WHP wrapper functions, but support for certain fields (e.g. XCR0) only arrived in later versions of the WHP API (Windows 10 RS5). For completeness, the project includes a small “bootloader”, which runs at CPL0 upon startup and manually initializes the final parts of the CPU prior to executing the target code. Unlike a physical CPU, which would start in 16-bit real mode, the virtual CPU has already been initialized to run in long-mode (64-bit), making the boot process slightly more straightforward.
The following steps are performed by the bootloader:
-
Load the GDT using the
LGDTinstruction. The source operand for this instruction specifies a 10-byte memory block which contains the base address and limit (size) of the table that was populated earlier. -
Load the IDT using the
LIDTinstruction. The source operand for this instruction uses the same format as LGDT described above. -
Set the TSS selector index into the task register using the
LTRinstruction. As mentioned above, the TSS descriptor exists as a special entry within the GDT (at0x40in this case). -
The XCR0 register can be set using the
XSETBVinstruction. This is an additional control register which is used for optional features such as AVX. The native process executes XGETBV to get the host value, which is then copied into the guest viaXSETBVin the bootloader.
This is an important step because DLL dependencies that have already been loaded may have set global flags during their initialization process. For example, ucrtbase.dll checks if the CPU supports AVX via the CPUID instruction on startup and, if so, sets a global flag to allow the CRT to use AVX instructions for optimization reasons. If the virtual CPU attempts to execute these AVX instructions without explicitly enabling them in XCR0 first, an undefined instruction exception will be raised.
-
Manually update
DS,ES, andGSdata segment selectors to their CPL3 equivalents (0x2B). Execute theSWAPGSinstruction to load the TEB base address fromMSR_KERNEL_GS_BASE. -
Finally, use the
SYSRETinstruction to transition into CPL3. Prior to theSYSRETinstruction,RCXis set to a placeholder address (CPL3 entry point), andR11is set to the initial CPL3 RFLAGS value (0x202). TheSYSRETinstruction automatically switches theCSandSSsegment selectors to their CPL3 equivalents fromMSR_STAR.
When the SYSRET instruction executes, a page fault will be raised due to the invalid placeholder address in RIP. The emulator will catch this page fault and recognize it as a “special” address. The initial CPL3 register values will then be copied into the virtual CPU, RIP is updated to point to a custom user-mode loader function, and execution resumes. This function loads all DLL dependencies for the target executable, populates the IAT table, executes TLS callbacks, and then executes the original entry point. The import table and TLS callbacks are handled at this stage, rather than earlier on, to ensure their code is executed within the virtualized environment.
Memory paging
All memory management for the guest must be handled manually. This means a paging table must be populated and maintained, allowing the virtual CPU to translate a virtual address to a physical address.
Virtual address translation
For those who are not familiar with paging in x64, the paging table has four levels: PML4, PDPT, PD, and PT. For any given virtual address, the CPU walks through each layer of the table, eventually reaching the target physical address. Modern CPUs also support 5-level paging (in case the 256TB of addressable memory offered by 4-level paging isn't enough!), but this is irrelevant for the purposes of this project.
The following image illustrates the format of a sample virtual address:
Using the example above, the CPU would calculate the physical page corresponding to the virtual address 0x7FFB7D030D10 via the following table entries: PML4[0xFF] -> PDPT[0x1ED] -> PD[0x1E8] -> PT[0x30]. Finally, the offset (0xD10) will be added to this physical page to calculate the exact address.
Bits 48 - 63 within a virtual address are unused in 4-level paging and are essentially sign-extended to match bit 47.
The CR3 control register contains the physical address of the base PML4 table. When paging is enabled (mandatory in long-mode), all other addresses within the context of the CPU refer to virtual addresses.
Page faults
When the guest attempts to access memory, the virtual CPU will raise a page fault exception if the requested page isn't already present in the paging table. This will trigger a VM Exit event and pass control back to the host. When this occurs, the CR2 control register contains the requested virtual address, although the WHP API already provides this value within the VM Exit context data. The host can then map the requested page into memory (if possible) and resume execution or throw an error if the target address is invalid.
Host/guest memory mirroring
As mentioned earlier, the emulator creates a child process, and all virtual memory within that process will be mapped directly into the guest using the same address layout. The Hypervisor Platform API allows us to map virtual memory from the host user-mode process directly into the physical memory of the guest. The paging table will then map virtual addresses to the corresponding physical pages.
Instead of mapping the entire address space of the process upfront, a fixed number of physical pages are allocated for the guest. The emulator contains a very basic memory manager, and pages are mapped "on demand." When a page fault occurs, the requested page will be paged in, and execution resumes. If all page "slots" are full, the oldest entry is swapped out to make room for the new one.
In addition to using a fixed number of currently mapped pages, the emulator also uses a fixed-size page table. The size of the page table is determined by calculating the maximum possible number of tables for the amount of mapped page entries. This model results in a simple and consistent physical memory layout but comes at the cost of efficiency. In fact, the paging tables take up more space than the actual page entries.
There is a single PML4 table, and in the worst-case scenario, each mapped page entry will reference unique PDPT/PD/PT tables. As each table is 4096 bytes, the total page table size can be calculated using the following formula:
PAGE_TABLE_SIZE = 4096 + (MAXIMUM_MAPPED_PAGES * 4096 * 3)By default, the emulator allows for 256 pages to be mapped at any one time (1024KB in total). Using the formula above, we can calculate that this will require 3076KB for the paging table, as illustrated below:
In practice, many of the page table entries will be shared, and a lot of the space allocated for the paging tables will remain unused. However, as this emulator functions well even with a small number of pages, this level of overhead is not a major concern.
The CPU maintains a hardware-level cache for the paging table known as the Translation Lookaside Buffer (TLB). When translating a virtual address to a physical address, the CPU will first check the TLB. If a matching entry is not found in the cache (known as a “TLB miss”), the paging tables will be read instead. For this reason, it is important to flush the TLB cache whenever the paging tables have been rebuilt to prevent it from falling out of sync. The simplest way to flush the entire TLB is to reset the CR3 register value.
Syscall handling
As the target program executes, any system calls that occur within the guest must be handled by the host. This emulator handles both SYSCALL instructions and legacy (interrupt-based) syscalls. SYSENTER is not used in long-mode and, therefore, is not supported by WinVisor.
Fast syscall (SYSCALL)
When a SYSCALL instruction executes, the CPU transitions to CPL0 and loads RIP from MSR_LSTAR. In the Windows kernel, this would point to KiSystemCall64. SYSCALL instructions won't inherently trigger a VM Exit event, but the emulator sets MSR_LSTAR to a reserved placeholder address — 0xFFFF800000000000 in this case. When a SYSCALL instruction is executed, a page fault will be raised when RIP is set to this address, and the call can be intercepted. This placeholder is a kernel address in Windows and won't cause any conflicts with the user-mode address space.
Unlike legacy syscalls, the SYSCALL instruction doesn't swap the RSP value during the transition to CPL0, so the user-mode stack pointer can be retrieved directly from RSP.
Legacy syscalls (INT 2E)
Legacy interrupt-based syscalls are slower and have more overhead than the SYSCALL instruction, but despite this, they are still supported by Windows. As the emulator already contains a framework for handling interrupts, adding support for legacy syscalls is very simple. When a legacy syscall interrupt is caught, it can be forwarded to the “common” syscall handler after some minor translations — specifically, retrieving the stored user-mode RSP value from the CPL0 stack.
Syscall forwarding
After the emulator creates the "main thread" whose context gets cloned into the virtual CPU, this native thread is reused as a proxy to forward syscalls to the host. Reusing the same thread maintains consistency for the TEB and any kernel state between the guest and the host. Win32k, in particular, relies on many thread-specific states, which should be reflected in the emulator.
When a syscall occurs, either by a SYSCALL instruction or a legacy interrupt, the emulator intercepts it and transfers it to a universal handler function. The syscall number is stored in the RAX register, and the first four parameter values are stored in R10, RDX, R8, and R9, respectively. R10 is used for the first parameter instead of the usual RCX register because the SYSCALL instruction overwrites RCX with the return address. The legacy syscall handler in Windows (KiSystemService) also uses R10 for compatibility, so it doesn’t need to be handled differently in the emulator. The remaining parameters are retrieved from the stack.
We don’t know the exact number of parameters expected for any given syscall number, but luckily, this doesn’t matter. We can simply use a fixed amount, and as long as the number of supplied parameters is greater than or equal to the actual number, the syscall will function correctly. A simple assembly stub will be dynamically created, populating all of the parameters, executing the target syscall, and returning cleanly.
Testing showed that the maximum number of parameters currently used by Windows syscalls is 17 (NtAccessCheckByTypeResultListAndAuditAlarmByHandle, NtCreateTokenEx, and NtUserCreateWindowEx). WinVisor uses 32 as the maximum number of parameters to allow for potential future expansion.
After executing the syscall on the host, the return value is copied to RAX in the guest. RIP is then transferred to a SYSRET instruction (or IRETQ for legacy syscalls) before resuming the virtual CPU for a seamless transition back to user-mode.
Syscall logging
By default, the emulator simply forwards guest syscalls to the host and logs them to the console. However, some additional steps are necessary to convert the raw syscalls into a readable format.
The first step is to convert the syscall number to a name. Syscall numbers are made up of multiple parts: bits 12 - 13 contain the system service table index (0 for ntoskrnl, 1 for win32k), and bits 0 - 11 contain the syscall index within the table. This information allows us to perform a reverse-lookup within the corresponding user-mode module (ntdll / win32u) to resolve the original syscall name.
The next step is to determine the number of parameter values to display for each syscall. As mentioned above, the emulator passes 32 parameter values to each syscall, even if most of them are not used. However, logging all 32 values for each syscall wouldn't be ideal for readability reasons. For example, a simple NtClose(0x100) call would be printed as NtClose(0x100, xxx, xxx, xxx, xxx, xxx, xxx, xxx, xxx, ...). As mentioned earlier, there is no simple way to automatically determine the exact number of parameters for each syscall, but there is a trick that we can use to estimate it with high accuracy.
This trick relies on the 32-bit system libraries used by WoW64. These libraries use the stdcall calling convention, which means the caller pushes all parameters onto the stack, and they are cleaned internally by the callee before returning. In contrast, native x64 code places the first 4 parameters into registers, and the caller is responsible for managing the stack.
For example, the NtClose function in the WoW64 version of ntdll.dll ends with the RET 4 instruction. This pops an additional 4-bytes off the stack after the return address, which implies that the function takes one parameter. If the function used RET 8, this would suggest that it takes 2 parameters, and so on.
Even though the emulator runs as a 64-bit process, we can still load the 32-bit copies of ntdll.dll and win32u.dll into memory - either manually or mapped using SEC_IMAGE. A custom version of GetProcAddress must be written to resolve the WoW64 export addresses, but this is a trivial task. From here, we can automatically find the corresponding WoW64 export for each syscall, scan for the RET instruction to calculate the number of parameters, and store the value in a lookup table.
This method is not perfect, and there are a number of ways that this could fail:
- A small number of native syscalls don't exist in WoW64, such as
NtUserSetWindowLongPtr. - If a 32-bit function contains a 64-bit parameter, it will be split into 2x 32-bit parameters internally, whereas the corresponding 64-bit function would only require a single parameter for the same value.
- The WoW64 syscall stub functions within Windows could change in such a way that causes the existing
RETinstruction search to fail.
Despite these pitfalls, the results will be accurate for the vast majority of syscalls without having to rely on hardcoded values. In addition, these values are only used for logging purposes and won't affect anything else, so minor inaccuracies are acceptable in this context. If a failure is detected, it will revert back to displaying the maximum number of parameter values.
Syscall hooking
If this project were being used for sandboxing purposes, blindly forwarding all syscalls to the host would be undesirable for obvious reasons. The emulator contains a framework that allows specific syscalls to be easily hooked if necessary.
By default, only NtTerminateThread and NtTerminateProcess are hooked to catch the guest process exiting.
Interrupt handling
Interrupts are defined by the IDT, which is populated before the virtual CPU execution begins. When an interrupt occurs, the current CPU state is pushed onto the CPL0 stack (SS, RSP, RFLAGS, CS, RIP), and RIP is set to the target handler function.
As with MSR_LSTAR for the SYSCALL handler, the emulator populates all interrupt handler addresses with placeholder values (0xFFFFA00000000000 - 0xFFFFA000000000FF). When an interrupt occurs, a page fault will occur within this range, which we can catch. The interrupt index can be extracted from the lowest 8-bits of the target address (e.g., 0xFFFFA00000000003 is INT 3), and the host can handle it as necessary.
At present, the emulator only handles INT 1 (single-step), INT 3 (breakpoint), and INT 2E (legacy syscall). If any other interrupt is caught, the emulator will exit with an error.
When an interrupt has been handled, RIP is transferred to an IRETQ instruction, which returns to user-mode cleanly. Some types of interrupts push an additional "error code" value onto the stack - if this is the case, it must be popped prior to the IRETQ instruction to avoid stack corruption. The interrupt handler framework within this emulator contains an optional flag to handle this transparently.
Hypervisor shared page bug
Windows 10 introduced a new type of shared page which is located close to KUSER_SHARED_DATA. This page is used by timing-related functions such as RtlQueryPerformanceCounter and RtlGetMultiTimePrecise.
The exact address of this page can be retrieved with NtQuerySystemInformation, using the SystemHypervisorSharedPageInformation information class. The LdrpInitializeProcess function stores the address of this page in a global variable (RtlpHypervisorSharedUserVa) during process startup.
The WHP API seems to contain a bug that causes the WHvRunVirtualProcessor function to get stuck in an infinite loop if this shared page is mapped into the guest and the virtual CPU attempts to read from it.
Time constraints limited the ability to fully investigate this; however, a simple workaround was implemented. The emulator patches the NtQuerySystemInformation function within the target process and forces it to return STATUS_INVALID_INFO_CLASS for SystemHypervisorSharedPageInformation requests. This causes the ntdll code to fall back to traditional methods.
Demos
Some examples of common Windows executables being emulated under this virtualized environment below:
Limitations
The emulator has several limitations that make it unsafe to use as a secure sandbox in its current form.
Safety issues
There are several ways to "escape" the VM, such as simply creating a new process/thread, scheduling asynchronous procedure calls (APCs), etc.
Windows GUI-related syscalls can also make nested calls directly back into user-mode from the kernel, which would currently bypass the hypervisor layer. For this reason, GUI executables such as notepad.exe are only partially virtualized when run under WinVisor.
To demonstrate this, WinVisor includes an -nx command-line switch to the emulator. This forces the entire target EXE image to be marked as non-executable in memory prior to starting the virtual CPU, causing the process to crash if the host process attempts to execute any of the code natively. However, this is still unsafe to rely on — the target application could make the region executable again or simply allocate executable memory elsewhere.
As the WinVisor DLL is injected into the target process, it exists within the same virtual address space as the target executable. This means the code running under the virtual CPU is able to directly access the memory within the host hypervisor module, which could potentially corrupt it.
Non-executable guest memory
While the virtual CPU is set up to support NX, all memory regions are currently mirrored into the guest with full RWX access.
Single-thread only
The emulator currently only supports virtualizing a single thread. If the target executable creates additional threads, they will be executed natively. To support multiple threads, a pseudo-scheduler could be developed to handle this in the future.
The Windows parallel loader is disabled to ensure all module dependencies are loaded by a single thread.
Software exceptions
Virtualized software exceptions are not currently supported. If an exception occurs, the system will call the KiUserExceptionDispatcher function natively as usual.
Conclusion
As seen above, the emulator performs well with a wide range of executables in its current form. While it is currently effective for logging syscalls and interrupts, a lot of further work would be required to make it safe to use for malware analysis purposes. Despite this, the project provides an effective framework for future development.
